Iron oxide red
Category:
Hotline:
- Product description
- Safety data sheet
- Product SGS inspection report
-
- Commodity name: Iron oxide red
- Commodity ID: 1034760798829633536
Iron oxide red pigment is suitable for use in various types of concrete prefabricated parts and building products as pigments or colorants, directly transferred into cement applications. Various indoor and outdoor colored concrete surfaces, such as walls, floors, ceilings, pillars, porches, pavements, parking lots, stairs, stations, etc.; various architectural ceramics and glazed ceramics, such as tiles, floor tiles, roof tiles, panels , terrazzo, mosaic tiles, artificial marble, etc.
§ Appearance:Red powder§ Chemical classification:Synthetic iron oxide red a-Fe2O3§ Pigment index:Pigment Red 101 (77491)§ CAS number:1309-37-1§ EEC number:215-168-2§ Molecular formula:Fe2O3§ Product performanceThe color is soft, and the color is excessive from the orange red to the purple red series. Tricyclic pigments have excellent pigment and chemical properties, high coloring power and hiding power, excellent light and weather resistance, and high temperature resistance. Insoluble in alkali, stable in a certain range of acidity, completely soluble in concentrated hydrochloric acid. It is insoluble in water and organic solvents and has excellent properties such as rust and UV resistance.§ Main product modelIron oxide red H110, H120, Y101, H130, China Red, H101 (1#, 2#), H190, etc.
§ Product Usage1. Iron oxide red pigment is suitable for use in various types of concrete prefabricated parts and building products as pigments or colorants, directly transferred into cement applications. Various indoor and outdoor colored concrete surfaces, such as walls, floors, ceilings, pillars, porches, pavements, parking lots, stairs, stations, etc.; various architectural ceramics and glazed ceramics, such as tiles, floor tiles, roof tiles, panels , terrazzo, mosaic tiles, artificial marble, etc.2, iron oxide red pigment is suitable for various paint coloring and protective substances, including waterborne interior and exterior wall coatings, powder coatings, etc.; also applicable to oily paints including epoxy, alkyd, amino and other primers and topcoats; Can be used in toy paints, decorative paints, furniture paints, electrophoretic paints and enamels.3, iron oxide red pigment is suitable for the coloring of plastic products, such as thermosetting plastics and thermoplastics, and the coloration of rubber products, such as car inner tubes, aircraft inner tubes, bicycle inner tubes and so on.4. In addition, iron oxide pigments can also be used for coloring paper and leather. At the same time, because of its excellent abrasiveness, it can be used as an abrasive in machinery, as a catalyst in the chemical industry, and as a raw material for producing other iron-containing products.§ ApplicationsThe product has good dispersibility, stable storage, good compatibility with other components in the application system, and can enhance the rust and UV resistance of the paint;Paint formula reference pigment amount: primer 25--30%; blend paint 20--30%; lacquer 15-25% (excluding body pigment)Water-based paint: Depending on the color, it can be configured in appropriate amount.§ Technical parameters and test methods of the pigment: The product implements the GB/T1863-2008 iron oxide pigment standard (MOD ISO1248:2006).Indicator name
unit
Index value
Test Methods
Color difference △E
≤1.0
Relative tinting strength
%
95～105
Titanium dioxide dilution(1:10)
Iron content (expressed as Fe2O3)
%
≥95
ISO1248:2006
Oil absorption
g/100g
Agreed
ISO787-5
Sieve residue（325目）
%
＞0.1，≤1
ISO787-7
Water soluble
%
≤0.3
ISO787-3
105 ° C volatiles
%
≤1.0
ISO787-2
pH value
Agreed
ISO787-9
1000 ° C / 0.5 h heat loss
%
≤5
ISO55913
Particle shape
spherical
Primary primary particle（D50）
μm
0.4-0.7
Seismic density
g/cm3
0.8-1.1
density
g/cm3
4.8
Lightfastness
level
7-8
Weather resistance
level
5
Heat resistance
℃
600
The above are the main technical indicators of the products, other indicators refer to the national standards of the products.§ Iron oxide red product color card：Color Card
model
primary color Diluted color (TiO2: pigment = 5:1) Iron oxide red H110
Iron oxide red H120
Iron oxide red Y101
Iron oxide red H130
China red
Iron oxide red H101(2*)
Iron oxide red H101(1*)
Iron oxide red H190
Since the actual conditions of use are outside our control, the application data provided by the company is only for reference, research and comparison by relevant personnel. Please be sure to apply the test in actual use. The company has the final interpretation right.Key words:- Iron oxide red
-
1. Product FeaturesMaterial characteristics: bright and pure color, color from orange to purple red series. It has good pigment and chemical properties, high coloring power and hiding power, excellent weather resistance and light resistance, and high temperature resistance. Insoluble in alkali, stable in a certain range of acidity, completely soluble in concentrated hydrochloric acid.Product Chinese Name: Iron Oxide RedEnglish name: Iron Oxide RedProduct common name: iron oxide redMain uses of the products: coatings, glass, ceramics, plastics, rubber, cement construction, etc., and because of their good abrasiveness, they can be used as abrasives in machinery.2. Composition/composition information:Chemical composition: Fe2O3Appearance: red powderIndex number: 77419CAS number: 1309-37-1EEC number: 215-168-23. Risk descriptionDescription of hazards: Not dangerous.A detailed description of the hazards of the substance to humans and the environment: so far the product is not a substance that requires mandatory hazard marking.4. First aid measuresAfter inhaling the substance: Fresh air should be taken immediately.After skin contact with the substance: rinse with soapy water.If the substance is inadvertently ingested: rinse with plenty of water for 10-15 minutes.5. Firefighting measuresExtinguish the fire source in the usual way.Remove nearby dangerous goods, remove their burning residues, and ventilate to remove combustion gas products.No special protection is required.Proper breathing apparatus may be required.6. Accidental leak response measuresReduce pollution to the environment: Do not enter the public facilities, sewers or public areas.Cleaning method/collection: When dust is generated, use a dry brush to clean.7. Storage methodSafe storage method: sealed to prevent dust from entering.Isolated from flammable and explosive materials.The product is not flammable.Store in a cool dry seal at room temperature.8. How to use and personal protectionWorker's protection: Take care to prevent the formation of dust when feeding.Respiratory protection: Wear a dust mask when the product forms dust.Eye protection: Wear eye mask/mask.Body protection: Wear suitable protective clothing.Hand protection: wear protective glovesOther protection: Keep away from food, beverages and tobacco, wash your hands before and after work.9. Physical and chemical propertiesAppearance and traits : red powderColor : Orange Red to Purple RedOdour : 无味PH : 3.5-7Relative density : 4.8g/cm3Tap density :0.8-1.1g/cm3Related safety data (varies with conditions)Melting point: 1565 °C dissolved)Flash point: UnknownFlammability: UnknownExplosive characteristics: UnknownSaturated steam pressure: unknown10. Stability and reactivityProduct performance is stable,It will not be harmful if handled as required.11. Toxicity dataPractical experience: This product does not pose a hazard to the body, and can be given proper proper treatment and hygiene prevention.12. Ecological dataDo not throw empty bags of product in the sewer or water without treatment,Do not store in a public warehouse.13. Packaging ProcessingContaminated packaging should be thrown into a suitable garbage dump.The contaminated packaging must be emptied of all residues and properly cleaned, and the uncontaminated packaging can be recycled for the next round.14. TransportationThe product is not a hazardous substance,Can be transported on national/international roads, railings, oceans and air.15. RestrictedHazard symbols and hazard indications: no hazard symbols.Additional data: A product that has not been used as a mandatory imprint so far.16. Other dataDetailed information on the existing product data of the department. All data is based on existing theories, and we guarantee that the product does not have any characteristics of dangerous goods and does not affect the establishment of an effective contractual relationship.
-
Product recommendation
Widely used as colorants for paint, water-based paint, ink, glass, ceramics, plastics, rubber, paper making, asbestos, leather, tipping paper, printing, adhesive tape color, cement, color asphalt, square floor, floor tiles and other building materials
Reasons for choosing us
Reliable product quality
Strictly control the whole process of production process according to the requirements of ISO9001: 2015 quality management system, use advanced testing instruments in the industry to control product quality according to the requirements of ISO1248:2006 standard, and ensure the consistency of quality and color of each batch of products.
Customizable pigment and processing
Our company's nationwide sales, wholesale, service providers and technical support network provide timely and complete after-sales service for local customers. The laboratory is responsible for the quality inspection of products and the development of new products, constantly meeting the needs of customers in new processes and new applications.
